3A 12/24V to 12/5/3.3V LM2596 LM2596S DC-DC Adjustable Step-down Power Supply Module

Price:

$ 1.38
USD
  2. Shop
  3. Modules & Sensors
  4. 3A 12/24V to 12/5/3.3V LM2596 LM2596S DC-DC Adjustable Step-down Power Supply Module
5W CREE XTE S3 High Power LED 8-20mm PCB Emitter Warm Neutral White Blue
5W CREE XTE S3 High Power LED 8-20mm PCB Emitter Warm Neutral White Blue
$ 1.07
$ 1.07
30W 40W 50W Driverless LED Light COB Chip Spotlight Size 110x58mm Emitting 60x30mm
30W 40W 50W Driverless LED Light COB Chip Spotlight Size 110x58mm Emitting 60x30mm
$ 5.15
$ 5.15

3A 12/24V to 12/5/3.3V LM2596 LM2596S DC-DC Adjustable Step-down Power Supply Module

https://www.qskj.cc/web/image/product.template/1063/image_1920?unique=e9a865c
(0 review)

$ 0.61 0.61 USD $ 0.61

¥ 4.40

Not Available For Sale

    This combination does not exist.

    Contact Us
    Categories :
    Build-in PCB Driver , Power Modules
    SKU :
    180630
    Share :
    Terms and Conditions :
    100% original guarantee
    Return within 30days
    Free delivery on all orders
    You may also like
    L298N Dual Channel PWM Motor Speed Driver Board
    L298N Dual Channel PWM Motor Speed Driver Board
    $ 0.37 $ 0.37
    LM317 DC-DC Linear Converter Buck Step Down Low Ripple Module for Arduino
    LM317 DC-DC Linear Converter Buck Step Down Low Ripple Module for Arduino
    $ 0.58 $ 0.58
    E27 PAM8406 5W*2 Digital Stereo Audio Power Amplifier Module Board
    E27 PAM8406 5W*2 Digital Stereo Audio Power Amplifier Module Board
    $ 0.83 $ 0.83
    MC34063A Reverse Voltage Module 3.6v-36v
    MC34063A Reverse Voltage Module 3.6v-36v
    $ 1.16 $ 1.16
    DC-DC 6V-32V TO 0.8-28V 150W 15A Buck-Boost Voltage Regulator QS-1212CBA-150W
    DC-DC 6V-32V TO 0.8-28V 150W 15A Buck-Boost Voltage Regulator QS-1212CBA-150W
    $ 40.12 $ 40.12
    AMS1117-3.3 DC-DC Step-Down Power Supply Buck Module lot(5 pcs)
    AMS1117-3.3 DC-DC Step-Down Power Supply Buck Module lot(5 pcs)
    $ 1.38 $ 1.38

    Description:

    LM2596 LM2596S DC-DC 3A 12/24V to 12/5/3.3V adjustable step-down power Supply module

    • Input voltage :3V ~ 40V

    • The output voltage : 1.5V ~ 35V

    • Output Current :3A( Max)

    • Conversion efficiency:92%( MAX )

    • Output ripple: <30mV

    • Switching frequency: 150KHz

    • Working temperature: -forty Five~ +85

    • Size :45mm * 25mm * 14mm(Long*Width*Hight)

    • The range of input voltage: 3 V to 40 V dc (input voltage must be higher than to the output voltage of 1.5 V above. Can't booster)

    • The range of output voltage: 1.5 V dc to 35 V voltage adjustable, high efficiency (92%) largest maximum output current is 3A.

    • Power (3-40V), power indicator light, the module is working properly.

    • Adjust the blue potentiometer knob (clockwise rotation generally boost,counter-clockwise rotationTurn down) and reach with a multimeter to monitor the output voltage required voltage..

    Note:

    •  Current work long hours is recommended for use in less than 2.5A, while adding bulkHeat sink (10W output above),because it is the step-down module, in order to ensure stable output Set,please keep the minimum 1.5V differential.

    Specification:

    • Weight: approx 100 g

    • Material: Steel,Plastic
