GY-33 TCS34725 Color Sensors /Identify Sensor Module

Description:

TCS34725 chip +mcu color recognition sensor module, IIC or serial communication, the output value of RGB

• 1, can be used as a simple TCS34725 module.

• 2, you can use the internal MCU to read the TCS34725 data, MCU calculated after the direct output of RGB, internal white balance procedures, support for serial /IIC read.

• GY-33 is a low-cost color recognition sensor module.

• Working voltage 3-5v, low power consumption, small size, easy to install.

• The principle of the work is that the illumination LED is illuminated, and the radiation is measured.

• The object, return the light passes through the filter detection ratio of RGB value

• according to the proportion of RGB value to identify the color.

• This module, there are two ways to read the data, that is, the

• Serial UART (TTL level) or IIC (2 lines).

• Serial port baud rate 9600bps and 115200bps, can be configured,

• There are continuous, ask the output of two ways, can be power down save settings.

• There are 7 simple color recognition, do not need to calculate the value of RGB.

• Can adapt to different working environment, and the single chip microcomputer and computer connection.

• In addition, the module can set the working mode of individual sensor chip,

• As a simple sensor module, MCU does not participate in data processing.

• Provide DIY, 51, STM32 microcontroller communication program,

• Does not provide the principle diagram and internal SCM source.

Two, product features and technical parameters

• (1), high cost

• (2), built-in MCU calculation of color

• (3), IIC, serial communication format

• (4) adjustable LED brightness

• (5), with the corresponding PC software

Three, product application

• (1) intelligent robot

• (2) teaching laboratory apparatus

• (3) product inspection of production line

• (4) color meter

• (5) led color detection
