DC12V/96W DC24V/192W LED light Human Body Induction Switch /LED Infrared Detection Sensor

Technical parameters

• Working temperature: -20 to +60

• Supply voltage: DC12V/24V

• Output: 4 channels

• Sensing distance: 5 ~ 8 M.

• Ham should angle: 120 degrees.

• External dimension: L89ΧW59ΧH35 mm

• Packing size: L96ΧW64ΧH65 mm

• Net weight: 80g

• Gross weight: 100g

• Static power consumption: <1W

• Output current: <8A

• Output power: 12v<96w 24v<192W

Direction for Use

• Connect the load wire at first, following by the power wire; Please ensure short circuit can not occur between connecting wire before you turn on the power;

• When the detected light up when the load was light, when people leave after 10 seconds, load lights automatically turn off.

• The controller signal output line and input line should be connected correctly.
