Brand: QSKJ
Model: QS-1235CCBA-100W
Features:
To constant current constant voltage (for driving high-power LED, and charge the battery)
Efficiency as high as 94%, fever little energy loss
Low ripple design, the load disturbance, 12V switch 12V 2A typical ripple 21mV
Breakdown after effectively prevent the direct input and output, security design (for safety equipment work)
And with input reverse voltage protection, output short circuit and over current protection
Casting aluminum enclosure design, seismic, water, heat, harsh environment adaptability 8. Pluggable terminal design, easy disassembly, more convenient connections
Where the power enough to work in parallel
Parameters:
Module Properties: non-isolated constant current and voltage can be automatically boost
Input Voltage :5-32V
output voltage: (1) adjustable (12-35V)
(2) fixed output (12 arbitrary choice between-35V
output constant current range :0.5-5A (100W MAX) (continuously adjustable)
Output Power: 100W maximum cooling power (input voltage greater than 10V, the input 8V output 60W MAX)
conversion efficiency: typical 92%
Operating temperature: Industrial grade (-40°c to +85°c) (ambient temperature exceeds 40 degrees, lower power use, or to enhance heat dissipation) shell surface temperature can not exceed 90 degrees
full load temperature rise : 40°c
load current: Typical
Load regulation: ± 2%
voltage regulation rate: ± 0.5%
dynamic response speed: 5% 200uS
short circuit protection: No output short circuit strict
undervoltage Protection: None
Input reverse polarity protection: Yes.
Installation: screw (diameter 3 mm), 2 mounting holes, 2 fixed hole spacing of 82 mm
Connection mode: you can plug terminals, pressure lines, does not require welding
Case: All aluminum, casting process, can work under adverse conditions
Driving LED simple adjustment of voltage and current methods (such as 10 series LED current 1. 7A 50W)
Module input power output is not connected LED, adjust the CV output voltage to approximately 34V;
CC multi-turn adjustment counterclockwise until you hear potentiometer which sent da da sound (potentiometer has been adjusted to the end);
Connecting LED, and the LED anode and cathode in series between the module outputs a current meter (ammeter internal resistance as small as possible, ammeter connecting wire as thick, short, so as not to affect the debugging results);
Power, this time should not be light or micro-LED light, observe the ammeter shows the current, slowly clockwise until the ammeter shows about regulating CC 1. 7A.
Remove the meter, direct electrical test machine.
Driving LED simple adjustment of voltage and current methods (such as 10 series LED current 1. 7A 50W)
Module input power output is not connected LED, adjust the CV output voltage to approximately 34V;
CC multi-turn adjustment counterclockwise until you hear potentiometer which sent da da sound (potentiometer has been adjusted to the end);
Connecting LED, and the LED anode and cathode in series between the module outputs a current meter (ammeter internal resistance as small as possible, ammeter connecting wire as thick, short, so as not to affect the debugging results);
Power, this time should not be light or micro-LED light, observe the ammeter shows the current, slowly clockwise until the ammeter shows about regulating CC 1. 7A.
Remove the meter, direct electrical test machine.
Applications:
Battery voltage regulator, 12V battery to it (10-14V) output voltage regulation in 12V, 24V battery output voltage in 12V.
Solar charge regulator, solar cells can now stabilize fluctuations in voltage and can charge the battery to avoid battery overshoot.
Constant current institutions can charge the battery, driving high power LED
The system before the class, ultra-high efficiency design, environmental protection, heat a small capacity loss.
1-4 high-power LED strings can be used to drive the battery charging, battery voltage, car voltage regulators, power equipment, etc.
