Brand: QSKJ
Model: QS-B305ABL-200A
Product Description:
Our protection board uses 26 imported high-power ultra-low internal resistance MOS tubes (13 discharge and 13 charge), which is by no means a low-power MOS on the market. The internal resistance of our single MOS tube is less than 3 milliohms and the peak current is 410A.
Adopt high-precision independent balancing IC, the balancing current can reach 100mA.
Increase TVS spike protection.
The continuous current is 24A (a small heat sink needs to be added), and the maximum peak current is 1200A.
Easily start the car, gasoline engine below 2.5 displacement.
Features:
- The protection board adopts advanced protection circuit. Original special protection IC,100A high Current and low internal resistance MOS (one MOS Internal resistance is 6.5 milliohm）,with perfect and stable charging and discharging protection function.
- Small volume and large current. It can be used in electric tools、Electric vehicle、UPSLarge Current Circumstances.
- Strong compatibility：Protective board supports the same port and split connection mode. Support 6-20 lithium batteries with series ternary and lithium iron phosphate（Attention: Ternary plates cannot be used in lithium iron phosphate batteries)
Parameters:
New Version Polymer Ternary Lithium/Lithium Manganese Oxide Battery Protection Board Parameters (Common Port: 3.6V/3.7V)
|
Protection Item |
Min |
Typ |
Max |
Unit |
|
Overcharge Voltage |
4.21 |
4.25 |
4.29 |
V |
|
Overcharge Release Voltage |
4.14 |
4.19 |
4.24 |
V |
|
Overcharge Protection Delay |
500 |
1000 |
1500 |
ms |
|
Overdischarge Voltage |
2.72 |
2.8 |
2.88 |
V |
|
Overdischarge Release Voltage |
2.9 |
3.0 |
3.1 |
V |
|
Overdischarge Protection Delay |
10 |
— |
— |
S |
|
Internal Resistance (+35°C) |
120A New Version: 0.55 (excluding wires) |
— |
— |
mΩ |
|
240A New Version: 0.40 (excluding wires) |
— |
— |
||
|
Discharge Protection Current |
120A New Version: 300 |
— |
— |
A |
|
240A New Version: 390 |
— |
— |
||
|
Peak Current |
120A New Version: 750 |
— |
— |
A |
|
240A New Version: 120A |
— |
— |
||
|
Same-Port Discharge Current (Continuous) |
120A New Version: 120A (with heatsink) |
— |
— |
A |
|
240A New Version: 240A (with heatsink) |
— |
— |
||
|
Overdischarge Current Protection Delay |
10 |
— |
— |
S |
|
Charge Protection Current |
None |
— |
— |
A |
|
Charge Current (Continuous) |
120A New Version: 90A (with heatsink) |
— |
— |
A |
|
240A New Version: 150A (with heatsink) |
— |
— |
||
|
Overcharge Current Protection Delay |
10 |
20 |
30 |
ms |
|
Standby Current |
115 |
— |
— |
μA |
|
Temperature Protection |
65 |
— |
— |
°C |
|
Intermittent Protection |
Yes |
— |
— |
— |
|
Short-Circuit Protection |
Yes |
— |
Loop Resistance >10 mΩ |
— |
|
Overcurrent Recovery Method |
Charge Activation / Load Disconnection |
— |
— |
— |
|
Balancing Function |
Yes |
— |
— |
— |
|
Balancing Voltage |
4.18 |
— |
— |
V |
|
Balancing Current |
110 |
— |
— |
mA |
New Version LiFePO4 Protection Board Parameters (Common Port: 3.2V)
|
Protection Item |
Min |
Typ |
Max |
Unit |
|
Overcharge Voltage |
3.81 |
3.85 |
3.59* |
V |
|
Overcharge Release Voltage |
3.7 |
3.75 |
3.8 |
V |
|
Overcharge Protection Delay |
500 |
1000 |
1500 |
ms |
|
Overdischarge Voltage |
1.92 |
2.0 |
2.08 |
V |
|
Overdischarge Release Voltage |
2.4 |
2.5 |
2.6 |
V |
|
Overdischarge Protection Delay |
10 |
— |
— |
S |
|
Internal Resistance (+35°C) |
120A New Version: 0.55 (excluding wires) |
— |
— |
mΩ |
|
240 A New Version: 0.40 (excluding wires) |
— |
— |
||
|
Discharge Protection Current |
120 A New Version: 300 |
— |
— |
A |
|
240 A New Version: 390 |
— |
— |
||
|
Peak Current |
120 A New Version: 750 |
— |
— |
A |
|
240 A New Version: 120A |
— |
— |
||
|
Same-Port Discharge Current (Continuous) |
120 A New Version: 120A (with heatsink) |
— |
— |
A |
|
240A New Version: 240A (with heatsink) |
— |
— |
||
|
Overdischarge Current Protection Delay |
10 |
— |
— |
S |
|
Charge Protection Current |
None |
— |
— |
A |
|
Charge Current (Continuous) |
120A New Version: 90A (with heatsink) |
— |
— |
A |
|
240A New Version: 150A (with heatsink) |
— |
— |
||
|
Overcharge Current Protection Delay |
10 |
20 |
30 |
ms |
|
Standby Current |
113 |
— |
— |
μA |
|
Temperature Protection |
65 |
— |
— |
°C |
|
Intermittent Protection |
Yes |
— |
— |
— |
|
Short-Circuit Protection |
Yes |
— |
Loop Resistance >10 mΩ |
— |
|
Overcurrent Recovery Method |
Charge Activation / Load Disconnection |
— |
— |
— |
|
Balancing Function |
Yes |
— |
— |
— |
|
Balancing Voltage |
3.59 |
— |
— |
V |
|
Balancing Current |
100 |
— |
— |
mA |
Accessories and Others
|
Name |
Quantity |
Specification |
Description |
Material |
|
Wiring Cable |
1 |
22AWG, 50cm length |
3F Terminal |
High-temp silicone wire |
|
(With Wire) Wire B- |
1 |
7AWG, 15cm length |
Black |
High-temp silicone wire |
|
(With Wire) Wire C- |
1 |
7AWG, 15cm length |
Blue |
High-temp silicone wire |
|
(Extended Copper Bar) Insulated Copper Bar B- |
1 |
1.54mm (Thickness + Width) |
— |
Pure Copper |
|
(Extended Copper Bar) Insulated Copper Bar C- |
1 |
1.54mm (Thickness + Width) |
— |
Pure Copper |
|
Mounting Hole |
47° |
93.5mm |
Supports screw fixation |
— |
|
Dimensions |
84.4 x 50 x 248 mm |
— |
— |
— |
|
Color |
Black (FCB) |
— |
— |
— |
|
Weight |
~108g |
— |
— |
— |
|
Packaging |
Anti-static bag |
— |
— |
— |
|
Operating Temperature |
-20°C to +65°C |
— |
— |
— |
|
Storage Temperature |
+40°C to +85°C |
— |
— |
— |
|
Storage Humidity |
90% |
No condensation |
— |
— |
Notes:
- Units assumed: "aS" → ms (milliseconds), "aΩ" → mΩ (milliohms), "HA" → μA (microamps).
- *Typo in LiFePO4 "Overcharge Voltage" Max value (3.59V) may need verification.
- Model numbers (e.g., 1204/2404) retained as original.
